ICOSO Cube PC
Introducing the ICOSO Cube PC – Updated Nov 2023!
This is a Intel® Core™ powered computer in a VESA mountable 6″ x 5″ x 2″ case (approx size). Featuring the 12 Generation Intel® Core™ i5-1240P and i7-1260P or 13th Generation i5-1360P and i7-1360P processors, with Intel® Iris® Xe Graphics, up to 64gb of DDR4-2666/3200 memory, M.2 2280 SSD slot for SATA/NVME PCIe Gen4 SSD up to 1 TB. With 2 HDMI ports and 1 Display port you can plug in multiple monitors to enhance your productivity. The computer includes 2 x 2.5 Gbe Intel® I225-V LAN ports, and 2 USB 2.x ports and 4 USB 3.x ports. A Type-C Thunderbolt port is also included. The ICOSO Cube PC comes with the latest Microsoft™ has to offer Windows 11 Pro. OR you can have Windows 10 Pro pre-installed, your choice.
The Cube PC is the Perfect Solution for Medical Offices, Dental Offices, Bank/Credit Union Teller Stations,
Tax/Accountants, your board/conference room, or anyplace that you need
to conserve desk space. It is VESA mountable to the back of your monitors,
and includes the mounting bracket and HDMI cable.
All of this at a price that’s much less than the competition. Download the Full Spec sheet.4
Specifications
| PROCESSORS: | Intel® Core™ Alder Lake-P i5-1240P ( 12 Core(4+8), 16 Threads, 3.4GHz~4.6GHz) i7-1260P ( 12 Core(4+8), 16 Threads, 3.4GHz~4.7GHz) i5-1340P ( 12 Core(4+8), 16 Threads, 3.4GHz~4.6GHz) i7-1360P ( 12 Core(4+8) 16 Threads, 3.7GHz~5.0GHz) |
| GPU: | Intel® Iris® Xe Graphics Graphics max 1.4Ghz |
| MEMORY: | 2 x SO-DIMM DDR4-2666/3200 16gb - max support 64GB 2 x SO-DIMM DDR5-3600/4800 16gb - max support 64GB for the i7-1360P only |
| VIDEO OUTPUT: | 2 – HDMI2.0 (max support 4K@60Hz) 1 – DP(max support 4K 4096×2304@60Hz) 1 – Type-C ( support display) |
| AUDIO and MIC: | Audio/MIC jack*1 |
| ETHERNET LAN: | Intel® Ethernet Controller(3) I225-V = 2 x 2.5Gbe LAN, RJ45 |
| WIFI: | Intel® Wi-Fi 6E AX210 160Mhz |
| STORAGE: | a. 1 x M.2 2280 SSD slot, support SATA/ NVME PCIe Gen4 SSD b. 1 x M.2 2280 SSD slot, support NVME SSD c. 1 x SATA III for 2.5″”HDD/SSD” |
| FRONT I/O: | Power Button, MIC /Audio port, USB3.0 * 4, Type-C (thunderbolt) |
| BACK I/O: | 2.5Gigabit LAN *2, HDMI 2.0 * 2, DP * 1, USB2.0 *2, COM 232 * 1 |
| POWER: | Input Power: 100- 240V AC, Output Power: 19V4.74A DC |
| SIZE: | Chassis: 158mm x 125mm x 49mm |
| OS: | Microsoft Windows 10 or 11 Pro. (can also run pfSense® for Firewall or Linux OS = subtract $30) |
| BIOS: | American Megatrends B005, 12/20/2022 |
| CHASSIS MATERIAL: | Plastic |
| ACCESSORIES: | Quick User Guide, AC Adapter , HDMI cable, VESA mount |
| VESA MOUNT: | Included, Support (70*70/100*100mm) |
| WARRANTY: | 1 Year Limited Depot Hardware Warranty (3yr Optional Depot Hardware Warranty = $120) |
| PRICING: | KC12i5 Pro – i5-1240P= $575 or KC12i7 Pro – i7-1260P = $700 (retail pricing - contact us for quote) KC12i5 Pro – i5-1340P= $625 or KC12i7 Pro – i7-1360P = $750 (retail pricing - contact us for quote) PC includes 16gb mem, 512gb SSD, Win 11 Pro, Wired Keyboard & Mouse, 1 VESA mounting bracket, 1 x HDMI cord, 1x power cord. |
| OPTIONAL FEATURES: | Wireless Keyboard & Mouse add $40 32gb Memory Total add $40 DDR4, $50 (DDR5 = I7-1360P) 64gb Memory Total add $125/$145, 256gb M.2 2280 subtract $20 , 1 TB M.2 2280 SATA SSD add $50 |
| DISCOUNTS: | 10 – 20 units = $10 off each, 20 – 30 units = $15 off each, 31+ units = $20 off each |
